Deskripsi
LIHAT BROSUR : Brosur Total Station Hi Target HTS 420R
Total station adalah alat instrumen optis/elektronik yang lengkap dapat mengukur sudut dan jarak sehingga dapat digunakan dalam pemetaan dan kontruksi dan bangunan. Alat ini terintegrasi dengan komponen pengukur jarak elektronik (electronic distance meter (EDM)) untuk membaca jarak dan kemiringan dari instrumen ke titik tertentu.
Alat ini memiliki ketelitian 2 detik yang dapat mengukur dengan baik dan juga akurat. Kemudian pengukuran jarak 600 meter tanpa menggunakan prisma (reflectorless) dan jarak pengukuran 6 km dengan bantuan prisma. Memori penyimpanan yang mampu menyimpan hingga 20.000 point.
Spesifikasi Total Station Hi Target HTS-420R
- Magnification : 30X
- Accuracy : 2
- Distance Measurement ( HTS-420R with Reflector )
- Single Prism : 3000m ( 9,842ft. )
- Three Prisms : 6000m ( 19,685ft. )
- Reflective Sheet : 800m ( 2,624ft. )
- Reflectorless Range : 600m ( 1,968ft. )
- Data Storage Internal Memory : 20,000 points
- Battery Operating Time : Approx.16 Hours
- Angle Measurement
- Measurement Method : Absolute Encoding
- Minimum Readout : 1/ 5/ 10 (0.3mgon/1.5mgon/3mgon) optional
- Accuracy : 2
- Distance Measurement (HTS-420 with Reflector)
- Single Prism : 3000m (9,842ft.) under good condition 3
- Three Prism : 6000m (19,685ft.) under good condition
- Reflective Sheet : 800m (2,624ft.)
- Accuracy : 2mm + 2ppm
- Measuring Time(Fine/Quick/Tracking):1.5s/1s/0.5s
- Telescope
- Magnification : 30X
- Field of View : 1 30 (2.7m at 100m)
- Minimum Focusing Distance : 1.2m
- Reticle : Illuminated
- Compensator
- System : Dual – axis liquid tilt sensor
- Working Range : 3
- Setting Accuracy : 1
- Communication
- Bluetooth
- Interface : Standard RS232, SD card, USB pen drive, mini-B
- Internal Data Memory : Approx. 20,000 Points
- Data Format : ASCII
- Operation
- Operation system : Real-time Operating System
- Display : Gray and white display with adjustable contrast; 280 X 160 pixels; 6 lines X 25 characters
- Keyboard : 2 sides Aplhanumeric backlit crystal keyboard
- Laser Plummet
- Type : Laser point, 4 brightness levels adjustment / Optical Plummet (optional)
- Centering Accuracy : 1 mm at 1.5m instrument height
- Power Supply
- Battery Type : Rechargeable Li-ion battery
- Voltage / Capacity : ZBA-400 : 7.4V (DC) / 3000mAh
- Operating Time With ZBA-400 : Optimal 16 hours (Continuous angle measurement every 30 seconds) /
- 10 hours ( typical)
- Measuring Times : Approx. 12000 times
- Weight
- Weight (Incl. Battery & Tribrach) : Approx. 5.5kg (12.1lb.)
- Environmental
- Operating Temperature : -20C ~. 50C (-4F to + 122F)
- Storage Temperature : -40C ~. 70C (-40F to + 158F)
- Dust & Water Proof (IEC60529 Standard) / Humidity : IP65. 95 % non-condensing
Kelengkapan
- 1 Unit Total Station Hi-Target HTS-420R
- 1x Battery
- 1x Charger Battery
- 1x Prisma Single
- 1x Prisma Polygon
- 1x Pole stik
- 2x Alumunium Tripod
